สายไฟ OLFLEX CLASSIC 110 2X0.5
รายละเอียด
LFLEX CLASSIC 110 PVC-Steuerleitung
Technical data
| Outside Ø | 4.80 mm |
|---|---|
| Test voltage | 4000 V |
| suited for cable carriers | No |
| Packaged | No |
| Sold per metre | Yes |
| Certification marks | VDE-Reg. Nr. 7030 |
| Number-coded | Yes |
| Wire ID code | Black conductors with white numbering (VDE 0293) |
| Colour | Grey |
| Halogen-free | No |
| Core layout | Finely stranded according to VDE 0295, Class 5/IEC 60228 Class 5 |
| Type | ÖLFLEX® CLASSIC 110 |
| Manufacturer part # | 1119752 |
| Min. temperature range (fixed installation) | -40 °C |
| Nominal voltage U0 | 300 V |
| Cross section | 2 x 0.50 mm² |
| Cross section (each core) | 0.50 mm² |
| Features | Oil-resistant, High flexural strength |
| Min. temperature range (flexible installation) | -5 °C |
| No. of leads | 2 x |
| Cable type | ÖLFLEX® CLASSIC 110 |
| Bend radius (no. of ODs for flexible installation) | 15 |
| Bend radius (no. of ODs for fixed installation) | 4 |
| Nominal voltage | 500 V |
| Max. temperature range (fixed installation) | +80 °C |
| Max. temperature range (flexible installation) | +70 °C |
| Category | Control wiring |
| Content | Sold per metre |
Highlights & details
- Nummerncode IEC 60332-1-2 High Security, Test voltage 4 kV
- ·
Description
Control and connection cable, especially under industrial conditions. Mainly in dry, damp or wet areas in normal mechanical stress.. Outdoors, under the temperature observation and not without UV protection. For free appliances, not continuously moving and without tensile loads or compulsory guidance, and for fixed installations.
Engineering, plant construction, painting, heating and air conditioning, power plant technology.
Optimized, small external diameter and therefore reduced space requirements. High insulation safety by 4 kV test voltage. During production, free from paint-wetting impairment substances (LBS-free / silicone), making it suitable for painting.
